Great Image Quality TFTs from Winstar Display (IPS) In Plane Switching technology means the display offers significant improvements in TFT panels of the light transmission, high quality colour reproduction and a super wide viewing angle. We offer a full range of modules; available sizes from mini IPS TFT of 0.96" to 15.6 inch IPS display, to deliver better performance in a range of demanding situations. We also offer higher brightness version (750~1100 cd/m2) as options for some models and resistive touchscreen (RTP) or capacitive touchscreen (PCAP). These wider view TFT IPS LCD displays can be operated from -20℃ to +70℃ or up to +85℃ with storage temperatures from -30℃ to +85℃ or +90℃.

IPS TFT Displays

WINSTAR's IPS TFT LCD modules harness the power of IPS panel (In-Plane Switching) technology, renowned for its faster response time, higher frequency transmittance, and superior color performance. Its most significant advantage lies in precise imaging with wider viewing angles, ensuring consistent color reproduction and high-quality images from various viewing positions. These displays are well-suited for a broad spectrum of applications.

IPS TFT Selector Guide PDF

Link To Winstar Website IPS TFT Page

IPS TFT

Features include:

  • High contrast
  • All round viewing
  • Consistent, accurate colour at all viewing angles
  • Fast response time
  • Variety of interfaces

IPS TFT

Applications include:

  • Industrial Controls
  • Information display
  • Instrumentation
  • Hand-held equipment
  • Access Control

Call the office for samples, demonstration and full data.

10.1" Quantum Dot IPS TFT

10.1" Quantum Dot IPS TFT
  • Diagonal Size: 10.1-inch
  • Resolution: 1920×1200 dots
  • Dimensions: 231.40×152.3×9.1 mm
  • Active area: 216.8064×135.504 mm
  • Driver IC: FL5893DA
  • Viewing Angle: 80/80/80/80(IPS)
  • Aspect Ratio: 16:10
  • Interface: LVDS
  • Brightness: 500 cd/m2
  • Operating Temperature: -20~+70℃

WF101NTYA4LNN0#000

12.1" High-Brightness IPS TFT LCD Module

12.1" High-Brightness IPS TFT LCD Module
  • Diagonal Size: 12.1-inch
  • Resolution: 1280×800 dots
  • Dimensions: 278.0×184.0×7.0 mm
  • Active area: 261.12×163.2 mm
  • Driver IC:
  • Viewing Angle: 85/85/85/85(IPS)
  • Aspect Ratio: 16:9
  • Interface: LVDS
  • Brightness: 1000 cd/m2
  • Operating Temperature: -20~+70℃

IPS TFT Selector Guide PDF
