Zigbee is a wireless technology developed as an open global standard to address the unique needs of low-cost, low-power wireless IoT networks. The Zigbee standard operates on the IEEE 802.15.4 low rate wireless personal area network. The protocol allows devices to communicate in a variety of network topologies

Zigbee SR series Hand-held remotes

Zigbee hand-held remote transmitters control Zigbee lighting receivers by pairing to the Zigbee network. Transmitters can be compatible with universal Zigbee gateway /coordinator and lighting devices .

  • Powered by 3x AAA batteries
  • Supports multiple groups
  • Up to 30metres transmission distance
  • Each group can bind up to 30 devices
  • Highly scaleable solution for thousands of devices
  • Compatible with universal ZigBee Gateway products
  • Supports Touchlink commissioning

 SR-SG2819S-RGB Remote PDF

Zigbee SR series Touch Panel Controls

The SR-ZG series of touch panel controllers  adopts Zigbee wireless technology  enabling switch, dimming and RGB/W colour control.  Using the Zigbee standard the panels are compatible with universal Zigbee gateway /coordinator and lighting devices .

  • Mains supply Input option 100-240VAC
  • Zigbee wireless protocol
  • Single or multi-group control
  • Each group can bind up to 30 devices
  • Highly scaleable solution for thousands of devices
  • Up to 30metres transmission distance
  • Built-in colour effects with adjustable speed

SR-1029-SB-5C PDF

Zigbee SR series Receiver/Drivers

The SR-Z series of Zigbee 3.0 RF LED drivers are compatible with a wide choice of universal Zigbee hand-held LED controllers and Touch Panel controls and other protocols such as DMX512, DALI, KNX, 0/1-10V.  Drivers are  available in constant voltage or constant current output mode.

  • Uses the latest Zigbee 3.0 protocol.
  •  Enables ON/OFF and light intensity control of connected LED products.
  • Constant Voltage output 12V-36VDC
  • Directly pairs to compatible Zigbee remote via Touchlink.
  • Supports self-forming Zigbee network without coordinator.
  • Supports "find and bind" mode to bind a Zigbee remote.
  • Compatible with universal Zigbee gateway or hub products.

Zigbee FUT-Z series Receiver/Drivers

The FUT-Z series Zigbee 2.4GHz controller /drivers comprises of  5 models designed to control dimming, CT, RGB, RGBW and RGB+CT. Controllers use Zigbee 3.0 and may be controlled from a range of compatible hand-held remotes RF Touch panels and Apps.

  • Input voltage 12V to 24VDC Output 12A
  • FUT036Z 1-channel output  Dimming
  • FUT035Z 2-channel output  CT
  • FUT037Z 3-channel output  RGB
  • FUT038Z 4-channel output RGBW
  • FUT039Z 5-channel output RGB+CT
  • Compatible with universal Zigbee gateway or hub products.
  • Supports Smartphone App & 3rd party voice control. Zigbee 3.0 Gateway required.

ZB-BOX1 Zigbee Gateway

The ZB-Box-1 facilitates a bridge connection from Zigbee RF 2.4GHz to Wifi wireless networks allowing connection of Smartphone Apps and third party voice controls such as Amazon Alexa and Google Assistant. The Gateway uses wireless Technology: WiFi 802.11 b/g/n (Zigbee 802.15.4) standard for connected devices.

  • Input voltage 5v Micro USB
  • Zigbee control distance 100 metres
  • Device sharing
  • Multiple scenes
  • Mi-Boxer Smart App control
  • Max connected devices 50
  • Compatible with universal Zigbee gateway or hub products.
  • Supports Smartphone App & 3rd party voice control. Zigbee 3.0 Gateway required.

SR-2818 Zigbee Gateway

Using the "Easy Home" App for Android or IOS the gateway is compatible with Zigbee network  Multiple rooms (zones) can be set up to control single colour or RGB/W LED lighting via Zigbee receiver drivers.

  • Input 12-24VDC
  • RF, Z-Wave or Zigbee
  • Wireless control Android / IOS device
  • Control lighting from free Easy Home app
  • Dimensions: 110x85x24.2mm
