Winstar’s WF series Monochrome TFT displays are a low cost alternative to full colour displays offering an impressive enhancement to a standard STN graphic display. Applied with active matrix TFT technology, the display performance has much better contrast, brightness and response time than traditional monochrome LCD modules.

Monochrome TFT

Monochrome TFT Display

Winstar’s WF series Monochrome TFT displays are a low cost alternative to full colour displays offering an impressive enhancement to a standard STN graphic display.

Features include:

  • Very high contrast (up to 900:1)
  • Brightness up to 1000cd/m2
  • Available in 3.5” 5.7” and 6.2” formats
  • Wide viewing angle
3.5" Monochrome TFT

Monochrome TFT Selector Guide PDF

Picture Display Format Model Number Size (inch) Outline Dimension (mm) Viewing Area (mm) Active Area (mm) View Direction Interface IC Part No. Control Board Brightness (cd/m²) Touch Screen Temperature (°C)
240x320 WF35NTVAJDNN0 3.5" 62.9 x 86.54 56.16 x 73.04 53.28 x 71.04 VA Glass MCU ST7511 No 500 No -30~80
320x240 WF57STIACDNN0 5.7" 160 x 109 118.28 x 88.64 115.2 x 86.4 12H MCU ST7511 No 1000 No -20~70
320x240 WF57STIACDNT0 5.7" 160 x 109 118.28 x 88.64 115.2 x 86.4 12H MCU ST7511 No 700 RTP -20~70
320x240 WF57STIACDNGA 5.7" 160 x 109 117.9 x 89.1 115.2 x 86.4 12H MCU ST7511 No 800 PCAP -20~70
640x320 WF62ATXGRDNN0 6.2" 170.32 x 88.3 141.6 x 73.4 140 x 70 VA Glass MCU ST7511 No 600 No -20~70
